Who We Are words about the company

The sheet metal forming industry of all kinds is considered one of the necessary industries, as this industry and its production lines have been developed The latest technologies of the era in order to obtain high quality and speed in manufacturing. Therefore, our company, using these renewable technologies, has always formed, since the beginning of the nineties, and based on the news Metal panels, especially air ducts of various shapes and accessories, which are frequently used in ventilation and air conditioning works Central as spinning and weaving industry facilities - dyes, gymnasiums ,etc. The company also manufactures doors for humidification stations and escape doors for textile factories, shelves and railways Mineral frequently used in warehouses and shopping centers. In order to ensure the distinguished and optimal service, we manufacture according to the measurements and specifications that suit the customer's need.

Air Ducts Description

it is mainly used in the work of ventilation and central conditioning and is manufactured in different thicknesses
FROM 0.8 MM TO 1.2 MM
the manufacturing method and thicknesses depend on the product measurements

In order to ensure that there is no air leakage at the joints, we put a 3 mm thick aerotype


Connection Method

The connection is made by flanges

  • if the duct area is smaller than 3.5 m2: Thickness : 0.8 MM
  • if the duct area is from 3.5 m2 to 6 m2: Thickness : 1 MM
  • if the duct area is bigger than 6 m2: Thickness : 1.2 MM

Circular Pipes Description

it is used for ventilation and central air conditioning in addition to transporting materials , especially spinning and weaving factories
The thickness of the sheet according to the diameter of the product
wich ranges from 125 MM to 900 MM
with a thickness from 0.8 MM to 1.2 MM


Connection Method

  • if circular ducts from 150 MM to 390 MM in diameter: Thickness : 0.8 MM
  • if circular ducts from 400 MM to 600 MM in diameter: Thickness : 1 MM
  • if circular section ducts from diameter 610 MM and above: Thickness : 1.2 MM

The blades are made of Aluminum and the body is made of Aluminum and are used in the work of central air conditioning and humidification

it is installed to prevent the transmission of vibrations caused by the potation of fans or motors to the air ducts

made of glavanized sheet and used in places that need natural ventilation with protection from other weather factors like rain and ducts , it can also be provided with a metal mesh to prevent the entry of tree leaves or birds through it.

Made of galvanized sheet with a thickness from 0.8 mm to 1.2 mm, It can be manufactured in different sizes upon request There are two models:
The first is normal, with a thickness from 0.8 mm to 1.2 mm
The second is reinforced with a thickness of 1.2 mm and is used for sections and large loads

ACCESSORIES

All accessories related to installation work we manufacture to ensure integrity and quality of work


In all honesty,We're so PROUD HAPPY of our clients...

Our customers are our partners in our success.
